LDW9 High Voltage Air Circuit Breaker (ACB), also known as an intelligent universal circuit breaker or frame circuit breaker, is designed for power distribution networks operating at an AC 50Hz, with a rated working voltage 800V~1140V and a rated working current of 7500A.
This ACB is utilized for the distribution of electrical energy and serves to protect cables and power equipment from various faults, including overload, under-voltage, short-circuits, and grounding issues. It incorporates a range of curve protection controllers that offer comprehensive protection functions, making it particularly suitable for power distribution networks that require enhanced power supply reliability and aim to minimize unnecessary power outages.
The 3H type smart controller is equipped with a communication interface that facilitates connectivity with field buses, thereby enabling four remote functionalities: “telemetry”, “remote adjustment”, “remote control” and “remote message” to fulfill the requirements of control automation. The integration of a leakage transformer with the corresponding smart controller provides leakage protection. This device can be utilized for motor fault protection within AC 50Hz, 400V network. Under normal conditions, it is suitable for infrequent starting of motors.
The products have successfully obtained “CQC”certification from the China Quality Certification Center.
